Overview
Offered with a variety of a field adjustable sensors, it is ideal for a broad range of applications from stairwells and parking garages to corridors and restrooms. Select models are also DLC approved.
Key features
- Bi-level fixtures operate at a low standby light level for energy savings, safety, and security
- Motion sensor options include Infrared, ultrasonic or high frequency
- IR and HF sensors available with optional ambient light sensor for daylight holdoff
- IR models available with optional Bluetooth® sensor
- UL Certified for Damp Locations and Union made in the USA
Photometric files & test reports
| Model | Length | Power | CCT | Input watts | Lumens | lm/W | Download |
|---|---|---|---|---|---|---|---|
DLXX48L-30-2CXX | 4′ | Low | 3000K | 22.5W | 2,790 | 124 | .ies · Report (PDF) |
DLXX48M-30-2CXX | 4′ | Medium | 3000K | 28.5W | 3,356 | 118 | .ies · Report (PDF) |
DLXX48H-30-2CXX | 4′ | High | 3000K | 49.6W | 5,935 | 120 | .ies · Report (PDF) |
Typical applications
stairwells, parking garages, corridors, restrooms, closets
