Overview
Direct round LED luminaire with integrated motion sensor for occupancy-driven on/off or bi-level dimming control. Surface-mount design with smooth acrylic diffuser and durable steel housing. UL Certified and Union made in the USA.
Key features
- Integrated motion sensor
- On/off or bi-level operation
- Surface-mounted round design
- Acrylic diffuser
- UL Certified, Union made in USA
Photometric files & test reports
| Model | Length | Power | CCT | Input watts | Lumens | lm/W | Download |
|---|---|---|---|---|---|---|---|
DLLR48LRA40 | 4′ | Low | 4000K | 22.9W | 2,716 | 118 | .ies · Report (PDF) |
DLLR48MRA40 | 4′ | Medium | 4000K | 31.1W | 3,462 | 111 | .ies · Report (PDF) |
DLLR48HRA40 | 4′ | High | 4000K | 52.6W | 5,920 | 112 | .ies · Report (PDF) |
Typical applications
corridors, restrooms, stairwells, storage rooms
